Audio Performance

Power Output (THD = 0.08%, two channels driven)
100 W per channel @ 8Ω, 200 W per channel @ 4Ω
Amplifier Technology
Class-D with PFFB (Post-Filter Feedback) technology
Total Harmonic Distortion (THD+N)
≤0.005%, -106 dB (A-weighted)
Signal-to-Noise Ratio (SNR)
≥120dB
Damping Factor
94
Frequency Response
20Hz – 20kHz ± 0.5dB
Impedence Range
2 – 8Ω

Audio Processing

Premium Audio Components
ESS 9039Q2M high-performance DAC, Dual TI TPA3255 Amps, TI OPA1612 op-amps for ultra-low distortion and rich, detailed sound.
Bit-Perfect Playback
Supports up to 192kHz/24-bit audio
Dynamic Range
≥120dB for high-resolution sound

Input & Output Options

Analog Inputs
1× RCA Stereo: Connects to external audio sources like CD players or PCs
Digital Inputs
1× Optical (TOSLINK) – Up to 192kHz/24-bit
HDMI ARC: Receives audio from TVs, PCM up to 192kHz/24-bit, and Dolby Digital 5.1 formats
Speaker Outputs
Gold-plated binding posts (supports banana plugs or bare wire connections)
USB Audio Output
Supports up to 8-channel 24-bit/192kHz; UAC 2.0 compliant
Sub Output
Dedicated output for powered subwoofers (RCA Mono)

Wireless & Network Connectivity

Wireless Connectivity
Bluetooth 5.3: Supports A2DP receiver and transmitter, AVRCP, HID, and works with the WiiM voice remote Wi-Fi 6 (Upgradeable to Wi-Fi 6E): Ensures stable and high-speed wireless streaming
Wired Network
Ethernet (100Mbps): Standard RJ45 port

EQ & Sound Customization

Input-Specific EQ
Independent settings for Wi-Fi, HDMI ARC, Optical, Bluetooth, Line-In
EQ Tools
▪ 24 Preset EQ Profiles
▪ 10-Band Graphic & Parametric EQ
▪ Built-in Room Correction with mic-guided acoustic tuning

Streaming & Smart Features

Streaming Protocols
▪ WiiM Home App
▪ Google Cast
▪ Spotify Connect
▪ TIDAL Connect
▪ DLNA, LMS
▪ Roon Ready (Certification Pending)
• Multi-Room Audio
Compatible with WiiM, Google Home, and Alexa multi-room systems
• Stereo Pairing
Supports L/R speaker setup for enhanced stereo imaging
• Home Theater Mode
Functions as front, center, or surround channel in a Dolby 5.1 setup via HDMI ARC
• Smart Presets
Quick access to favorite playlists, sources, or routines
• Alarm Clock
Configurable time, repeat schedule, and music source

Touch Display

Screen
3.5” glass-covered capacitive touchscreen
Functions
▪ Playback controls, album art, EQ adjustment, input switching
▪ Queue view, preset access, VU meters, time/date in standby
▪ Custom wallpapers and onboarding setup (OOBE)
▪ Supports firmware updates directly via screen

Design & Controls

Chassis
Precision-machined unibody aluminum for durability & heat dissipation
Physical Controls
Multifunctional rotary knob (Volume, Play/Pause)
Thermal Management
Copper heat pipe, large aluminum heatsink, unibody aluminum case, and precision PID thermal control
Cooling System
Passive, silent operation
